| COLOUR | Forest green | CASSETTE | Shimano LG300, 11-46T, 9 speed |
|---|
| FRAME | 6061-T6 aluminium, multi-shaped tubing; Single Chain Ring (SCR) 1x-specific design; 1.125–1.5in tapered Zero-Stack headtube; full 300mm reamed depth 30.9mm seat tube; Post Mount 180mm disc dropout; SRAM UDH spec derailleur hanger; 12mm x 148mm Boost. | CHAIN | KMC XGlide, 116 links |
|---|
| FORK | SR Suntour XCR 34 29in, 130mm travel, 44mm offset, black stanchions, air spring, adjustable compression and rebound, tapered steerer, 110mm x 15mm Boost thru axle | CRANKSET | Shimano CUES U4000, 30T chainring, 170mm, 9 speed, 52mm chainline, three-piece crankset |
|---|
| REAR SHOCK | N/A | BOTTOM BRACKET | Shimano BB-UN101, square taper, 122.5mm |
|---|
| HEADSET | ZS44 upper, ZS56 lower, 1 1/2in Lower and 1 1/8in upper caged bearings | SEATPOST | TransX size specific dropper post, 30.9mm (size S-M 150mm travel; sizes LG-XL 170mm travel) |
|---|
| REAR HUB | Alloy, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole, HG freehub | SADDLE | Whyte Custom |
|---|
| FRONT HUB | Alloy, 15mm x 110mm Boost spacing, 32 hole | HANDLEBAR | Whyte 6061 alloy, 15mm rise, 31.8mm bar bore, 760mm wide |
|---|
| SPOKES | 2.0mm, black stainless, brass nipples | STEM | Whyte alloy, 35mm extension, 31.8mm bar bore |
|---|
| RIMS | Pinned joint, 30mm internal width, tubeless ready, 32 hole | GRIPS | Whyte Trail lock-on |
|---|
| TYRE | Maxxis Rekon 29in x 2.4in front and rear | BRAKES FRONT | Tektro M285 hydraulic disc brake, two piston,180mm diameter disc rotor |
|---|
| SHIFT LEVERS | Shimano CUES U4000, 9 speed, Band On clamp | BRAKES REAR | Tektro M285 hydraulic disc brake, two piston,180mm diameter disc rotor |
|---|
| FRONT MECH | N/A | BRAKE LEVERS | Tektro M285 |
|---|
| REAR MECH | Shimano CUES U4000, 9 speed | PEDALS | Fibre reinforced composite platform

 |
|---|
