Frame
Spark RC Carbon HMF Integrated Suspension Technology Flex Pivot, Adjustable head angle Syncros Cable Integration System BB92, UDH Interface, 12x148mm with 55mm Chainline
-
Fork
FOX 32 Float Rhythm Grip 3-Modes, Kabolt 15x110mm axle, 44mm offset, tapered steerer Reb. Adj., Lockout, 120mm travel
-
Rear Shock
FOX Float LV Custom EVOL Performace Trunnion 3 modes, Lockout-Trail-Descend DPS, Reb. Adj. Travel 120mm, T165X45mm
-
Remote System
SCOTT TwinLoc Technology Suspension & Dropper Remote 3 Suspension modes
-
Rear Derailleur
SRAM Eagle 70 Transmission 12 Speed
-
Shifters
SRAM Eagle 70 Trigger
-
Crankset
SRAM Eagle 70 Transmission DUB, 55mm CL, 34T
-
Chainguide
SCOTT custom
-
BB-Set
SRAM DUB PF 92 MTB Wide, shell 41x92mm
-
Chain
SRAM CN Eagle 70 Transmission
-
Cassette
SRAM Eagle XS 1270 V2 Transmission 10-52
-
Brakes
SRAM DB4 4-Piston Disc
-
Rotor
SRAM Centerline CL Rotors 180/F and 160/R
-
Handlebar
Syncros Fraser 2.0 XC Alloy 6061 D.B. Flat Bar, 8°, 740mm, Syncros Performance XC lock-on grips
-
H'stem
Syncros XC 2.0 Syncros Cable Integration System -12° rise, 6061 Alloy, 31.8mm, 1 1/8"
-
Seatpost
Syncros Duncan Dropper 1.5XC, 31.6mm, all sizes 100mm
-
Seat
Syncros Belcarra V2.0 Cut Out CRMO rails
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
-
Hub (Front)
Formula CL-811, 15x110mm
-
Hub (Rear)
Formula CL-148S, 12x148mm Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools
-
Spokes
Stainless Black 15G, 1.8mm
-
Rims
Syncros X-30SE, 32H, 30mm Tubeless ready
-
Front Tire
Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead Tubeless Ready, EXO
-
Rear Tire
Maxxis Rekon Race, 29x2.4", 120TPI Foldable Bead Tubeless Ready, EXO
-
Approx weight in KG
12.8 (Tubless setup)
-
Approx weight in LBS
28.22 (Tubless setup)
-
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
