Frame
Alloy Frame
-
Suspension
Integrated Suspension Technology
-
Kinematic
Virtual 4 Link kinematic, Adjustable head angle
-
Cable System
Syncros Cable Integration System
-
Interface
Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready
-
Travel
Front: 150mm, Rear: 150mm
-
Fork
RockShox Psylo Silver RC Air, E-Bike, Comp & Reb Adj., QR Axle 15x110mm axle, 44mm offset, tapered steerer, 150mm travel
-
Rear Shock
X-Fusion O2 Trunnion PRO RL, Lockout, Reb. Adj., T185X55mm
-
Drive Unit
EU: 25kmh, INT: 20mph, Bosch Performance Line CX (BDU384Y)
-
Battery
PowerTube 800Wh
-
Display
Bosch System Controller, Mini Remote
-
Charger
2A Charger
-
Rear Derailleur
Shimano Deore RD-M6100 SGS, Shadow Plus, 12 Speed
-
Shifters
Shimano Deore SL-M6100-IR, Rapidfire Plus
-
Crankset
FSA Alloy
-
Chainguide
*thirteen, e*spec Slider
-
Chainring
FSA 12 Speed 34T chainring
-
Chain
Shimano CN-M6100
-
Cassette
Shimano CS-M6100, 10-51
-
Brakes
Shimano MT420 4 Piston Disc
-
Rotors
Front: SM-RT64 CL 220mm, Rear: SM-RT64 CL 203mm
-
Handlebar
Syncros Hixon 2.0 Alloy 6061, Size S & M 15mm rise, Size L & XL 25mm rise, back sweep 8°, 780mm
-
Grips
Syncros Performance XC lock-on grips
-
Stem
Syncros AM 2.0, Syncros Cable Integration System, 4° rise, 6061 Alloy, 31.8mm, 1 1/8"
-
Seatpost
Syncros Duncan Dropper Post 2.5, 31.6mm, S size 125mm, M size 150mm, L size 170mm, XL size 200mm
-
Seat
Syncros Tofino 2.5 Regular
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
-
Hub (Front)
Formula CL-811, 15x110mm
-
Hub (Rear)
Formula ECT-148M, Boost 148x12mm
-
Spokes
Stainless Black
-
Rims
Syncros MD30, 32H, 30mm, Pin Joint, Tubeless ready
-
Front Tire
Maxxis Forekaster 29x2.6", 120TPI Foldable Bead, EXO, TR Tubeless ready, 3C Maxx Terra
-
Rear Tire
Maxxis Forekaster 29x2.6", 120TPI Foldable Bead, EXO, TR Tubeless ready, 3C Maxx Terra
-
Lights
Syncros integrated rear fender light, Front Light Cable pre-installed
-
Approx weight in KG
25.8
-
Approx weight in LBS
56.88
-
Max. System Weight
130kg (The overall weight includes the bike, the rider, the equipment, and possible additional luggage.)
